Java API pro řízení projektů k vytváření a konverzi souborů Microsoft Project

Začínáme s Aspose.Tasks pro Javu

Doporučený způsob instalace Aspose.Tasks pro Javu je přes Maven repozitář. Můžete snadno použít Aspose.Words pro Java API přímo ve svých Maven projektech s jednoduchou konfigurací.

 //Define the Aspose.Tasks for Java API dependency in your pom.xml as follows
<dependencies>
	<dependency>
	<groupId>com.aspose</groupId>
	<artifactId>aspose-tasks</artifactId>
	<version>20.10</version>
	<classifier>jdk18</classifier>
	</dependency>
</dependencies>

Vytvořit nový soubor projektu pomocí Javy

Software Developers can create new empty projects from scratch using Aspose.Tasks for Java. This is useful when you need to generate project files dynamically. The Library supports a wide range of Microsoft Project file formats, including MPP, XML, and MPX. At present, Aspose.Tasks for Java provides the facility to create XML project files only. The following lines of code shows how software developers can create a simple project file in XML format.


public class CreateEmptyProjectFile {
    public static void main(String[] args) {
        // ExStart: CreateEmptyProjectFile
        // For complete examples and data files, please go to https://github.com/aspose-tasks/Aspose.Tasks-for-Java
        // The path to the documents directory.
        String dataDir = Utils.getDataDir(CreateEmptyProjectFile.class);

        // Create a project instance
        Project newProject = new Project();

        newProject.save(dataDir + "project1.xml", SaveFileFormat.Xml);

        //Display result of conversion.
        System.out.println("Project file generated Successfully");
        // ExEnd: CreateEmptyProjectFile
    }
}

Čtení souborů projektů pomocí Java API

One of the fundamental features of Aspose.Tasks for Java is the ability to read Microsoft Project files. The library allows software developers to load an existing project file with just a couple of lines of code and extract valuable information from project files. The Project class can be used to achieve this tasks, you need to provide path to MPP or XML document and returns a Project object which can be used to manipulate project data. The following example shows, how software developers can read a project file online inside Java applications.


String sharepointDomainAddress = "https://contoso.sharepoint.com";
String userName = "admin@contoso.onmicrosoft.com";
String password = "MyPassword";

ProjectServerCredentials credentials = new ProjectServerCredentials(sharepointDomainAddress, userName, password);
ProjectServerManager reader = new ProjectServerManager(credentials);

for (ProjectInfo p : (Iterable)reader.getProjectList())
{
    System.out.println("Project Name:" + p.getName());
    System.out.println("Project Created Date:" + p.getCreatedDate());
    System.out.println("Project Last Saved Date:" + p.getLastSavedDate());
}

for (ProjectInfo p : (Iterable)reader.getProjectList())
{
    Project project = reader.getProject(p.getId());
    System.out.println("Project " + p.getName() + " loaded.");
    System.out.println("Resources count:" + project.getResources().size());
}

Zpracování úkolů a plánování v Java aplikacích

Aspose.Tasks for Java supports create mew tasks, task scheduling and allows software developers to manage task dependencies effectively. It enables developers to modify project data effortlessly. You can update tasks, resources, and other details programmatically. There are several important features part of the library that allows users to handle project tasks, such as adding new tasks, getting and setting tasks properties, associating calendars with particular tasks, manage task duration in projects, managing critical and effort-driven tasks, and many more. The following examples increases and decreases the task duration to 1 week and half week respectively.

// Create a new project and add a new task
Project project = new Project();
Task task = project.getRootTask().getChildren().add("Task");

// Task duration in days (default time unit)
Duration duration = task.get(Tsk.DURATION);
System.out.println("Duration equals 1 day:" + duration.toString().equals("1 day"));

// Convert to hours time unit
duration = duration.convert(TimeUnitType.Hour);
System.out.println("Duration equals 8 hrs: "+ duration.toString().equals("8 hrs"));

// Increase task duration to 1 week and display if duration is updated successfully
task.set(Tsk.DURATION, project.getDuration(1, TimeUnitType.Week));
System.out.println("Duration equals 1 wk: " + task.get(Tsk.DURATION).toString().equals("1 wk"));

// Decrease task duration and display if duration is updated successfully
task.set(Tsk.DURATION, task.get(Tsk.DURATION).subtract(0.5));
System.out.println("Duration equals 0.5 wks: " + task.get(Tsk.DURATION).toString().equals("0.5 wks"));

Konverze dat projektu do PDF pomocí Java API

Aspose.Tasks for Java makes it easy for software developers to load and save project data to various important file formats inside Java applications. The Project class exposes the Save method which can be used to save a project in various formats. The Save method allows users to load and render project data to PDF file format with just a couple of lines of Java code. The following example demonstrates how to Render project data to PDF using Java commands.

// The path to the documents directory.
String dataDir = Utils.getDataDir(SaveAsPdf.class);

// Read the input Project file
Project project = new Project(dataDir + "project6.mpp");

project.save(dataDir + "Project5.pdf", SaveFileFormat.PDF);

// Fitting contents to cell size
Project project1 = new Project(dataDir + "project6.mpp");
SaveOptions o = new PdfSaveOptions();

// Set the LegendOnEachPage property to false to hide legends

// Set the row height to fit cell content
o.setFitContent(true);
o.setTimescale(Timescale.Months);
o.setPresentationFormat(PresentationFormat.TaskUsage);
project1.save("result_months.pdf", o);
o.setLegendOnEachPage(false);
project1.save(dataDir + "result_months_WithoutLegend.pdf", o);

// Display result of conversion.
System.out.println("Process completed Successfully");
