CAD 도면을 생성, 편집 및 변환하는 Java API

Java용 Aspose.CAD의 Maven 저장소

 //First, you need to specify the Aspose Maven Repository configuration/location in your Maven pom.xml as follows:

<repositories>
	<repository>
	<id>AsposeJavaAPI</id>
	<name>Aspose Java API</name>
	<url>https://releases.aspose.com/java/repo/</url>
	</repository>
</repositories>

//Define Aspose.PDF for Java API Dependency

<dependencies>
	<dependency>
	<groupId>com.aspose</groupId>
	<artifactId>aspose-cad;/artifactId>
	<version>22.12</version>
    <classifier>20.12</classifier>
	</dependency>
</dependencies>

라이브러리는 Aspose.CAD 제품 페이지에서 직접 다운로드할 수 있습니다.

Java API를 통해 3D AutoCAD 이미지를 PDF로 내보내는 방법은 무엇입니까?

String dataDir = Utils.getDataDir(Export3DAutoCADImagesToPDF.class) + "ExportingCAD/";
String srcFile = dataDir + "conic_pyramid.dxf";

Image cadImage = Image.load(srcFile);

CadRasterizationOptions rasterizationOptions = new CadRasterizationOptions();
rasterizationOptions.setPageWidth(500);
rasterizationOptions.setPageHeight(500);
rasterizationOptions.setTypeOfEntities(TypeOfEntities.Entities3D);
rasterizationOptions.setLayouts(new String[] {"Model"});

PdfOptions pdfOptions = new PdfOptions();
pdfOptions.setVectorRasterizationOptions(rasterizationOptions);

cadImage.save(dataDir + "Export3DImagestoPDF_out_.pdf", pdfOptions);

Java API를 통해 DWG 파일을 렌더링하는 방법?

// Load the CAD file
Image image = Image.load("input.dwg");

// Create an instance of CadRasterizationOptions
CadRasterizationOptions rasterizationOptions = new CadRasterizationOptions();
rasterizationOptions.setPageWidth(1000);
rasterizationOptions.setPageHeight(1000);

// Set the render options
PdfOptions pdfOptions = new PdfOptions();
pdfOptions.setVectorRasterizationOptions(rasterizationOptions);

// Save the output file
image.save("output.pdf", pdfOptions);

Java API를 통해 AutoCAD DGN 형식을 PDF로 변환하는 방법?

// load an existing DGN file as DgnImage.
DgnImage dgnImage = (DgnImage)Image.load(dataDir + "Nikon_D90_Camera.dgn");
// Create an object of CadRasterizationOptions class and define/set different properties
PdfOptions options = new PdfOptions();
CadRasterizationOptions vectorOptions = new CadRasterizationOptions();
vectorOptions.setPageWidth(1500);
vectorOptions.setPageHeight(1500);
vectorOptions.setNoScaling(true);
vectorOptions.setAutomaticLayoutsScaling(false);
options.setVectorRasterizationOptions(vectorOptions);
OutputStream outStream = new FileOutputStream(dataDir + "ExportDGNToPdf_Out.pdf");
// Call the save method of the DgnImage class object.
dgnImage.save(outStream, options);
