Perl SDK для создания, редактирования, манипулирования и конвертации 3D‑файлов

Установите Aspose.3D Cloud Perl SDK через CocoaPods

cpan AsposeCloud::3D

Вы можете скачать скомпилированную общую библиотеку со Aspose.3D Cloud Perl SDK страницы продукта.

Как конвертировать 3D‑модель в PDF с помощью Perl SDK?

# Get your ClientId and ClientSecret from https://dashboard.aspose.cloud (free registration required).

	my $config = AsposeThreeDCloud::Configuration->new('base_url' => 'https://api.aspose.cloud');
    my $client = AsposeThreeDCloud::ApiClient->new( $config);
    my $oauth_api = AsposeThreeDCloud::OAuthApi->new($client);

    my $grant_type = 'client_credentials';
    my $client_id = 'MY_CLIENT_ID';
    my $client_secret =  'MY_CLIENT_SECRET';
    my $result = $oauth_api->o_auth_post(grant_type => $grant_type, client_id => $client_id, client_secret => $client_secret);
    my $access_token  = $result->access_token;

    my $new_config = AsposeThreeDCloud::Configuration->new('access_token' =>  $access_token, 'base_url' => 'https://api.aspose.cloud/v3.0');
    $new_client = AsposeThreeDCloud::ApiClient->new( $new_config);
	my $api = AsposeThreeDCloud::ThreeDCloudApi->new($new_client)

	my $name = 'Aspose.Upload.3d';
    my $newformat = 'pdf';
    my $newfilename = 'saveasformat.pdf';
    my $folder = '3DTest';
    my $is_overwrite = 'true';
    my $storage = undef;

	my $result = $api->post_convert_by_format(name => $name, newformat => $newformat, newfilename => $newfilename, folder => $folder, is_overwrite => $is_overwrite, storage => $storage);

Как создать базовый 3D‑коробку через Perl API?

use AsposeCloud::3D::ApiClient;
use AsposeCloud::3D::Configuration;

my $config = AsposeCloud::3D::Configuration->new(
    app_sid => 'YourAppSID',
    app_key => 'YourAppKey',
);

my $api_client = AsposeCloud::3D::ApiClient->new(config => $config);

use AsposeCloud::3D::ObjectByThreeDsModelApi;
use AsposeCloud::3D::CreateEntityRequest;
use AsposeCloud::3D::Box;

my $object_api = AsposeCloud::3D::ObjectByThreeDsModelApi->new(api_client => $api_client);

my $box = AsposeCloud::3D::Box->new(
    width  => 5.0,   # Replace with your desired width
    height => 5.0,   # Replace with your desired height
    depth  => 5.0,   # Replace with your desired depth
);

my $create_entity_request = AsposeCloud::3D::CreateEntityRequest->new(
    name   => 'Box',           # Replace with your entity name
    box    => $box,
    folder => 'your_folder',   # Replace with your desired folder
);

my $result = $object_api->post_create_entity(request => $create_entity_request);

if ($result->status eq 'OK') {
    print "Entity created successfully.\n";
} else {
    print "Error: " . $result->status . "\n";
}

Как извлечь 3D‑сцену из файла и конвертировать её в формат GLTF?

use AsposeCloud::3D::SceneApi;
use AsposeCloud::3D::SaveOptions;

my $scene_api = AsposeCloud::3D::SceneApi->new(api_client => $api_client);

my $input_path = 'input_scene.obj';   # Replace with the path to your input 3D scene file
my $output_path = 'output_scene.gltf'; # Replace with the desired output format and path

my $save_options = AsposeCloud::3D::SaveOptions->new(
    save_format => 'gltf',              # Replace with your desired output format
    file_name   => $output_path,
);

my $result = $scene_api->post_export_scene(file => $input_path, save_options => $save_options);

if ($result->status eq 'OK') {
    print "Scene extracted and converted successfully. Output saved at $output_path\n";
} else {
    print "Error: " . $result->status . "\n";
}
