用于创建、编辑和转换 3D 模型的 Python API

开始使用 Aspose.3D for Python via .NET

通过 .NET 稳定版安装 Aspose.3D for Python 的最简方法是使用 pip。请使用以下命令以顺利完成安装。

pip install aspose-3d

通过 Python API 生成并加载 3D 场景

Aspose.3D for Python via .NET 已全面支持从头创建新的 3D 场景，并使用 Python 命令将其保存为任何受支持的文件格式。该库还提供了读取现有 3D 场景、对现有 3D 进行修改、将 3D 场景保存为 PDF、从受密码保护的 PDF 打开现有场景、检测文件格式、从 PDF 文件中提取 3D 内容、在加载 3D Obj 文件之前设置加载选项等功能。

import aspose.threed as a3d

# For complete examples and data files, please go to https://github.com/aspose-3d/Aspose.3D-for-.NET

# The path to the documents directory.

# Create an object of the Scene class

scene = a3d.Scene()

# Save 3D scene document

scene.Save("document.fbx", a3d.FileFormat.FBX7500ASCII)

通过 Python API 渲染 3D 场景

Aspose.3D for Python via .NET 使软件开发人员能够在自己的 Python 应用程序中加载和渲染 3D 场景。该库支持高质量的 3D 场景渲染，包括抗锯齿、景深、运动模糊等。它还支持导入和导出多种 3D 文件格式，包括 FBX、OBJ、STL 和 3DS。这意味着您可以轻松地将现有的 3D 模型导入到场景中，或将 3D 场景导出为兼容的格式。它支持诸如在 3D 几何体上投射和接收阴影、基于硬件的 3D 几何渲染、从相机将 3D 视图渲染为图像格式、渲染 3D 场景的全景视图等功能。以下代码示例展示了软件开发人员如何渲染 3D 场景的全景视图并保存为图像格式。

from aspose.pydrawing.imaging import ImageFormat
from aspose.pydrawing import Color
import aspose.threed as a3d

# load the scene

scene = Scene.from_file("vc.glb")

# create a camera for capturing the cube map

cam = a3d.entities.Camera(a3d.entities.ProjectionType.PERSPECTIVE)
cam.near_plane = 0.1
cam.far_plane = 200
cam.rotation_mode = a3d.entities.RotationMode.FIXED_DIRECTION
scene.root_node.create_child_node(cam).transform.set_translation(5, 6, 0);

# create two lights to illuminate the scene

scene.root_node.create_child_node(a3d.entities.Light("", a3d.entities.LightType.POINT).transform.set_translation(-10, 7, -10)
light = a3d.entities.Light()
light.color = Color.cadet_blue
scene.root_node.create_child_node(light).transform.set_translation(49, 0, 49)

# create a renderer

# Create a cube map render target with depth texture, depth is required when rendering a scene.

rt = renderer.render_factory.create_cube_render_texture(a3d.render.RenderParameters(False), 512, 512)

# create a 2D texture render target with no depth texture used for image processing
final = renderer.render_factory.CreateRenderTexture(a3d.render.RenderParameters(False, 32, 0, 0), 1024 * 3 , 1024)

# a viewport is required on the render target

rt.create_viewport(cam, a3d.utilities.RelativeRectangle.from_scale(0, 0, 1, 1))
renderer.render(rt)

# execute the equirectangular projection post-processing with the previous rendered cube map as input

equirectangular = renderer.get_post_processing("equirectangular")

# Specify the cube map rendered from the scene as this post processing's input

equirectangular.input = rt.targets[0]

# Execute the post processing effect and save the result to render target final

renderer.execute(equirectangular, final)

# save the texture into disk

final.targets[0].save("panorama.png", ImageFormat.PNG)

在 3D 文档中使用动画

Aspose.3D for Python via .NET 允许软件开发人员使用 Python 库在 3D 文档中创建和处理动画。该库包含了众多动画处理功能，例如渲染动画场景、在 3D 文件中设置目标摄像机、创建骨骼动画、处理形变目标以及混合多个动画。下面的示例演示了如何使用 Python 命令创建一个简单的动画。

import clr
clr.AddReference("Aspose.3D")
from Aspose.ThreeD import *

# create a new scene
scene = Scene()

# create a new camera
camera = Camera()
camera.Name = "Camera"
scene.RootNode.CreateChildNode(camera)

# create a new mesh
mesh = Mesh()
mesh.Name = "Mesh"
vertices = Vector3[]
vertices.append(Vector3(0, 0, 0))
vertices.append(Vector3(0, 1, 0))
vertices.append(Vector3(1, 1, 0))
vertices.append(Vector3(1, 0, 0))
mesh.Vertices = vertices
mesh.Triangles = [0, 1, 2, 0, 2, 3]

# create a new node for the mesh
meshNode = Node()
meshNode.Name = "MeshNode"
meshNode.Translation = Vector3(0, 0, 0)
meshNode.CreateChildNode(mesh)

# add the mesh node to the scene
scene.RootNode.CreateChildNode(meshNode)

# create a new animation track for the mesh node
track = AnimationTrack(meshNode, AnimationTargetType.Translation)

# create a new keyframe at time 0
keyframe1 = Keyframe()
keyframe1.Time = 0
keyframe1.Value = Vector3(0, 0, 0)
track.Keyframes.Add(keyframe1)

# create a new keyframe at time 1
keyframe2 = Keyframe()
keyframe2.Time = 1
keyframe2.Value = Vector3(0, 0, 5)
track.Keyframes.Add(keyframe2)

# create a new animation clip
clip = AnimationClip("Clip")
clip.Duration = 1
clip.Tracks.Add(track)

# add the animation clip to the scene
scene.Animations.Add(clip)

# save the scene to a file
scene.Save("animation.fbx", FileFormat.FBX7400ASCII)

使用 Python API 处理多边形

Aspose.3D for Python via .NET 使软件开发人员能够在 Python 应用程序中向其 3D 模型添加和管理多边形网格。该库支持多种与多边形网格管理相关的功能，例如从文件加载多边形网格、创建多边形网格、将 3D 模型中的所有多边形转换为三角形、将多边形网格导出到文件等。下面的示例展示了用户如何通过创建 Mesh 对象并向其添加顶点和面来创建多边形网格。

# Create a mesh
mesh = Mesh()

# Add vertices
mesh.Vertices.Add(Vector3(0, 0, 0))
mesh.Vertices.Add(Vector3(0, 0, 1))
mesh.Vertices.Add(Vector3(0, 1, 0))
mesh.Vertices.Add(Vector3(1, 0, 0))

# Add faces
mesh.Faces.AddPolygonFace(0, 1, 2)
mesh.Faces.AddPolygonFace(0, 1, 3)
mesh.Faces.AddPolygonFace(0, 2, 3)
mesh.Faces.AddPolygonFace(1, 2, 3)

# Export the polygon mesh to a file

# Create a scene and add the mesh to it
scene = Scene()
scene.RootNode.CreateChildNode(mesh)

# Save the scene to a file
scene.Save("mesh.obj", FileFormat.WavefrontOBJ)
